SUMNER
Mobile
Jobsite Storage Cart
MacRack™
•
Patented stacking feature: stack similar
carts together or with other Stacking
Mac Rack products
•
Shipped assembled with 6" heavy duty
casters
•
Durable powder coat finish
•
1,000 lb. load capacity
SUMNER
Mobile Pipe Cart
Pipe Mac™
•
Transports 2,000 lb of pipe,
individually or up to a height of
34"
•
Six 6" heavy duty casters
•
Center-positioned casters makes
rolling the Pipe Mac easy and
enables quick cart rotation for
tight turns
•
Posts pull out for compact storage
•
Stacks when not in use
SUMNER
Cricket Carts
Cricket™
•
Transport 20 ft pipe lengths up to
1,000 lbs
•
Ideal job-site material carrier
•
Comes with ratchet hold-down strap
and 16" tubed tires
•
Weighs only 70 lbs can be shipped
U.P.S.
•
Quick handle disconnect for compact
storage
Uses leverage to lift pipe
1. Use ratchet to secure cricket to pipe
2. Use handle to flip cricket & pipe
3. Reposition handle
Great for flanges, fittings and valve
SUMNER
Grasshopper Cart
Grasshopper®
Enables one man to lift 2,000 lbs.
Unassisted!
•
Special sliding chain block design
accommodates long and short loads
•
Carries up to 20" diameter pipe, toolboxes, fittings, and valves
•
ST-401 Grasshopper
•
Length: 12’ (366 cm)
•
Width: 36” (91 cm)
•
Height: 40” (102 cm)
•
Load Capacity Weight lbs. (kg): 20 (610)
•
Load Capacity Width in. (cm): 20 (51)
SUMNER
2 Ton Aluminum Gantry
GH2T
Lightweight, portable and easily assembled GH2T Gantry Lift for mechanical contractors. The GH2T Gantry
lift has a lift capacity of up to 2 metric tons (4,400 lbs) and is available in 4 Imperial sizes (8, 10, 12 and 15 foot)
•
Simpler to transport, assemble and adjust than comparable Gantry lifts
•
The entire assembly is light enough to be erected by a two-man crew
•
The advanced design allows a pivoting feature where the beam with trolley is inserted into receiver of each A-Frames then raised and final
bolting of beam occurs
•
Height adjustments can be made on either side by one man using the adjustable mast lifting handle and removable quick-action mast locking
pin
•
Beams come with convenient carrying handles on both ends
•
A-frame assemblies fold up and lock in folded position with plunger pins
•
The entire assembly is pinch-point free
•
The Sumner GH2T Gantry lift consists of 3 main components: two A-frames and a cross beam. A-frames lock in folded position using
plunger pins and feature a removable quick action locking pin. Adjustable lifting handle allow height adjustments to be made in 6-inch
increments. Each A-frame has two 8-inch lockable casters and weighs 113 lbs with casters. The trolley features a set screw that holds it in
place during assembly and weights approximately 15 lbs. Cross beams come in seven sizes (8, 10, 12 and 15 foot) and feature two span
adjustments on either end of 13-inches as well as nylon carrying handles.
Item #
Weight (lbs.)
SU783317
165
Item #
Weight (lbs.)
SU783230
170
Item #
Weight (lbs.)
SU782699
70
Item #
Weight (lbs.)
SU780351
165
Item #
Model
No.
Max/Min
Height To
Lifting Eye
(A)
Max Height
To Top Of
Beam (B)
MaxHeight
To Top Of
Trolley (C)
Max
Working
Span (D)
Span
Between
Wheels (E)
Height
Adjustment
(F)
Span
Adjustment
(G)
Max Width
Of A Frame
(H)
Weight
(lbs.)
SU785101 GH2T-7.5 113”/83”
131”
2
¹⁄₂
”
142”
15’
6”
13”
60
³⁄₄
”
328
SU785100 GH2T-15 113”/83”
131”
2
¹⁄₂
”
52”
7.5’
6”
13”
60
³⁄₄
”
287
