195
GREENLEE TEXTRON INC.
Pocket Cable Strippers
•
Stripping tool
•
For power and
telecommunications cables
•
Capacity: 3/16" - 1-1/8" dia. (#8 AWG-600 kcmil (MCM) THHN)
GREENLEE TEXTRON INC.
Digital Multimeter
•
Auto and manual ranging
•
Non-contact and single-probe voltage
detection
•
Beep-Jack™ audible and visible warning to
guard against improper A and mA terminal plug in
•
High visibility 6000 count LCD display
•
Capacitance and temperature measurement
capability
•
Low impedance mode
•
AutoCHECK ™ feature provides automatic
selection of AC volts, DC volts, or resistance with
low impedance for ghost-voltage elimination
•
True RMS
•
Peak (crest) hold; min, max
•
Auto power off, display backlight, analog bar graph
•
PC interface capability using optional USB RS-232 cable with
data recording PC software
•
Lifetime Limited Warranty
•
Voltage Measurement: 60mV to 1000V AC/DC
•
Amperage Measurement: 600mA to 8A AC/DC
•
Resistance: 600¾ to 60M¾
•
Frequency (Hz): 50 ~ 400
•
Measurement Category: Cat IV 300V; Cat III 600V, Cat II 1000V
GREENLEE TEXTRON INC.
Non-Contact
Voltage Detectors
•
Automatic self-test verifies the integrity of
the unit
•
Bright LEDs and audible alarm sound if
voltage is present
•
Silent-mode feature for use in quiet settings
•
Safe, non-contact voltage detection
•
Use to detect voltage in outlets, lighting fixtures, circuit breakers,
wires, and cables or to find a break in a wire.
•
Automatically turns off after five minutes of non-use to conserve
battery life
•
Low battery indicator
Specifications:
•
Voltage Detection: 50V – 1000VAC
•
Frequency: 50-500 Hz
•
Measurement Category: CAT IV, 1000V
GREENLEE TEXTRON INC.
Ranging Multimeter
Manual
•
Multi-purpose meter for most electrical
needs. Includes elastomer boot to protect
meter from damage. AC/DC voltage, DC
amperage measurement. Temperature
measurement. Audible continuity and diode
tests. Tests 1.5V and 9V batteries.
•
Voltage measurement: AC V: 200.0, 600 V;
DC V: 200.0, 2000 mV; 20.00, 200.0, 600V
Amperage Measurement: DC A: 20.00,
200.0 mA Temperature measurement: -40 to 1832 F,
(-40 to 1000 C) Measurement Category: CAT III, 300V; CAT II,
600V
GREENLEE TEXTRON INC.
Clamp-On Meters
•
True RMS for the most accurate measurement
when harmonics are present
•
AC amperage, AC/DC voltage, frequency and
resistance measuring capability
•
Dual hall sensor for DC amperage accuracy
•
Easy to read backlit display for use in low light
conditions
•
Peak and data hold to capture measurement
•
Min/Max feature for added versatility
•
Analog bar graph to view quick changes
•
Auto zero for DCA measurement
•
Amperage Measurement: 400.0; 600 A, Voltage Measurement:
400.0; 600 V, Resistance: 400.0 Ohms, Frequency: 0.400 kHz,
Display: 4000 count LCD display, Jaw Opening: 1.38 in. (35 mm),
Measurement Category: Cat III; 600 V per UL 3111-1
GREENLEE TEXTRON INC.
Pipe and Wire Locater
Tracker II™
•
Traces the path and determines
the depth of wires and metallic
pipes on active or dead systems
without having to deactivate the
system
•
Lightweight receiver provides
audible and visual indications of signal strength
•
Transmitter output and receiver sensitivity are fully adjustable for
maximum accuracy
•
Transmitter offers three methods of connection: direct, inductive
coupler, and inductive antenna
•
Includes transmitter assembly, receiver assembly, inductive
coupler (clamp), built-in inductive antenna, two 8 ft. (2.4 m) test
leads with heavy-duty alligator clips and durable polyethylene
case
•
High frequency transmitter provides range up to 4,000 ft. (1,219 m)
and depths up to 7 ft. (2 m)
•
Receiver is 32 in. long (813 mm)
•
Battery operated (eight AA and one 9V battery are included)
# Molded carrying case included
Item #
GR1900
Item #
GRDM-510A
Item #
GRGT-12
Item #
GRDM-40
Item #
GRCM-950
Item #
GR501
