501
UNISTRUT
Brackets
P1075
•
Use for P1000, P1100, P2000,
P4001 Channels
•
Safety Factor: 2-1/2”
•
Material: 1/4” thick steel
•
Allowable Moment for fitting only.
Channel may determine overall capacity
•
Call to specify material and finish
UNISTRUT
Brackets
P294X Slot Up
•
Safety Factor 2
¹⁄₂
”
•
Mounted on 12 ga. channel
•
Call to specify material, finish and
length
UNISTRUT
Brace fittings
P2815 Adjustable
•
30° Minimum adjustment
•
Call to specify material and finish
UNISTRUT
Brace Fittings
P2815D Adjustable
•
30° Minimum adjustment
•
Call to specify material and finish
UNISTRUT
Brace Fittings
P2458-XX Knee Braces
Design Loads:
•
Compression: 1500 Lbs.
(6.67 kN)
•
Tension: 300 Lbs. (1.33kN)
•
Call to specify material, finish
and length
UNISTRUT
Beam Clamp
P2675
•
Clamp Materials: .105" (2.7) thick
steel.
•
Clamp P2675 is designed for light
duty rod suspension.
•
It also may be used with
P3016-1024 or P3016-1420 nut
as illustrated above for mounting
insulators, etc.
•
Call to specify material and finish
UNISTRUT
Beam Clamp
P16XX
•
Size A: 5/8”-11
•
Size B: 1/4”
•
Size C: 1/2” x 1-1/2”
•
Size D: 15/16”
•
Design Load: 1,600 lbs.
•
Call to specify material and finish
UNISTRUT
Beam Clamp Straps
P1657A Retainer Strap
•
For beams under 7/8” thick flange
•
Flange Width: 9”
•
12 Gage
•
Size A: 12”
•
Used With Beam Clamp: P1651 AS
•
Call to specify material and finish
Item #
UTP1075
Item # ‘A’ Size Uniform Load (lbs.)
UTP2946 18”
400
UTP2947 24”
300
Item #
UTP2815
Item #
UTP2815D
Item #
UTP2458
Item #
UTP2675
Item #
UTP1651AS
Item #
UTP1657A
