www.edgecs.com
594
Anchors & Fastener Systems
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
ITW REDHEAD
T3 Fastening System
Magazine Fuel Powered
Ramset®
•
25% more power
•
Larger diameter pin (.125) for higher
stick rate
•
Deep leg track capability
•
One step fuel injected system
•
15-pin strip, 45-pin magazine
ITW REDHEAD
Fuel and Pin Packs
Gas Tool Fasteners
•
Each Fuel Cell contains 1000
shots
•
Bigger pin (.125 dia) means better
success rate
•
New 15 pin strip means less
loading and more shooting
•
Our new patented Point Collation
virtually eliminates jams
•
Fuel cell vs. powder load comparison: The average cost savings to
deliver 1000 shots for the Ramset T3 fuel cell is between 50-70%
less expensive compared to powder
•
1000 per box
ITW REDHEAD
Mechanical Pin
with Washer
Gas Tool Fasteners
•
Used for the attachment of light gage
metal to concrete and steel such as
HVAC duct strap to concrete
•
Plated pin pre-assembled to a 1/2” domed washer (500 per box)
•
Shank diameter = .125 Step Pin .104/.118
•
Head diameter = .300 (M012=.250)
•
Will fit R150 & T3SS with optional work contact element P/N
M150200
ITW REDHEAD
Top Hat Pin
Gas Tool Fasteners
•
Used for general purpose fastening to concrete
•
100 per box
•
Shank diameter = .125 Head diameter = .300
ITW REDHEAD
T3 Fuel Cartridges
T3SS and T3MAG
Ramset®
•
Replaces conventional powder loads and drives more
than 1000 pins
•
Fuel injection means no additional steps of preparing a
fuel cell
•
Click the fuel cell in place and the tool is ready to go
ITW REDHEAD
Fuel Cartridges
Ramset®
•
Replaces conventional powder loads and drives more
than 1000 pins
•
Cell–T2, R150, E150 & M150
ITW REDHEAD
T3SS Extension
Pole Tool
Ramset®
•
Easy to operate Comfortable "motorcycle" grip replaces
handbrake mechanisms
•
Sturdy design 25% thicker than similar poles for
greater support
Item #
RAT3MAG
Item #
Desc.
RAT3012
¹⁄₂
" steel pin with T3 fuel cell
RAT3034B
³⁄₄
" concrete pin with T3 fuel cell
RAT3034S
³⁄₄
" step shank pin with T3 fuel cell
RAT3100
1" concrete pin with T3 fuel cell
Item #
Desc.
RAM012
¹⁄₂
" Plated step pin with domed washer
RAM034
³⁄₄
" Plated pin with domed washer
RAM034BB
³⁄₄
" Premium step pin with domed washer
RAM100
1" Plated pin with domed washer
Item #
Desc.
RAMP034TH
³⁄₄
" Plated pin with top hat
Item #
RAT3FUEL
Item #
RAR-FUEL
Item # Length (ft.)
RAEPOL6
6
