1/4” Hex Drive Nutsetter
Magnetic
Apex
1/4” Hex Drive
Bit Holder
Magnetic
Apex
Multi-Craft® Drill
Chuck
Jacobs®
•
Ideal for corded or cordless
reversible or non-reversible
power drills
•
Through-hardened jaws for hard,
wear resistant gripping surfaces
Keyless Drill Chuck
Jacobs®
•
Patented keyless design produces
greater bit ripping force than
conventional keyed chucks
•
Hand-Tite® keyless operation
increases operator productivity and
convenience by speeding bit
changeovers and eliminating downtime caused by loss of chuck
keys
Plain Bearing Chuck
Thread Mounted/Heavy-Duty
Jacobs®
•
Heavy-duty model for threaded mounting
•
Jaws center-ground for absolute straightness and alignment
•
Jaws specially treated to ensure extended thread life and high gripping surface hardness
•
Fluted sleeve standard
Item # Size (in.) OA Length (in.)
Socket Nose Dia
(in.)
APMDA-08
¹⁄₄
1
³⁄₄
⁷⁄₁₆
APMDA-10
⁵⁄₁₆
1
³⁄₄
¹⁄₂
APMDA-12
³⁄₈
1
³⁄₄
⁹⁄₁₆
APMDB-08
¹⁄₄
2
⁹⁄₁₆
⁷⁄₁₆
APMDB-10
⁵⁄₁₆
2
⁹⁄₁₆
¹⁄₂
APMDB-12
³⁄₈
2
⁹⁄₁₆
⁹⁄₁₆
APMDB-14
⁷⁄₁₆
2
⁹⁄₁₆
⁵⁄₈
Item # Overall Length (in.)
APM-490
2
³¹⁄₃₂
APM-490-2
2
APM-490-6
6
Item #
Model
No.
Cap.
Range
Min. (in.)
Cap.
Range
Max. (in.)
Mount
Thrd.
Key No.
PJA30598
¹⁄₂
Cap.
0.078 0.500
³⁄₈
- 24 KK
Item #
Cap. Range
Min. (in.)
Cap. Range
Max. (in.)
Mount
Thrd.
OALgth.
(in.)
PJA30354 0.040
0.375
³⁄₈
- 24 2.00
PJA31038
0.062
0.500
¹⁄₂
- 20 2.90
PJA31037
0.062
0.500
³⁄₈
- 24 2.90
Item #
Maximum Capacity Range
in. (mm)
Mount
Thread Key No.
Closed Length
Dimension in. (mm)
Open Length
Dimension in. (mm)
Sleeve Dia.
Dimension in. (mm) Model No.
PJA6255
0.250 (6.5)
³⁄₈
-24 K7
2.23 (57)
1.74 (44)
1.33 (34)
7BA
³⁄₈
