143
RIDGE TOOL CO.
Power Pipe Cutter
2-1/2” to 8”
Model 258
The Ridgid Model 258 Power Pipe
Cutter is uniquely engineered to cut
2-1/2” to 8” schedule 10/40 steel
pipe, galvanized pipe, rigid conduit
etc. at the job site or in the shop
•
Powered by the Ridgid No. 700 Power Drive, the 258 is a
displacement cutter that provides square cuts
•
Great for cutting pipe for groove joining
•
Adaptable for beveling
Specifications:
•
Cutting capacity: 2-1/2” to 8” schedule 10/40 steel pipe
Standard Equipment:
•
One Ridgid 774 square drive adapter; one 8-1/2” HD cutter wheel
assembly; one hydraulic ram and foot pump; two 2-1/2” to 12” ball
transfer pipe supports
RIDGE TOOL CO.
8-1/2” H-D Cutter
Wheel
Model E-258
RIDGE TOOL CO.
1/8 to 1-1/8”
Midget Tubing Cutter
Self-Feeding
Model 118
The self-feeding cutter wheel requires
the operator to only tighten the knob
once to make a cut. The Model 118 is designed for use in restricted
spaces on small diameter hard & soft copper, aluminum and brass.
•
Easy to use in hard-to-reach areas because the knob only needs
to be tightened once
•
Adjustable to any size from 1/4”-1-1/8” OD
•
Spare E-3469 Cutter Wheel in Knob
•
Also available with optional Ratchet Handle
RIDGE TOOL CO.
Tubing Cutters
Midget - Close Quarters
•
Specifically designed for use in
restricted spaces on small
diameter, hard and soft copper,
aluminum, brass and plastic
tubing, rollers include grooves for
close-to-flare cuts
•
Strong, lightweight slide and wheel housing, large knurled feed
screw knob gives easy control of cutting pressure for clean cuts
•
Model 117 includes a self-feeding cutter wheel that automatically
cuts after tightening the knob only once (AUTOFEED™), as well
as a special knob for easier tightening of the feedscrew
•
Models 110 and 117 include spare cutter wheel in knob
RIDGE TOOL CO.
Tubing & Conduit
Cutters
With New X-CEL Features
•
Clean, square cuts are easily
made on copper, brass, aluminum,
and thin-wall conduit
•
Now includes X-CEL Knob for quicker cutting
•
Nos. 10, 15 and 20 feature a convenient fold-away reamer
•
No. 30 is rated for larger diameter steel and stainless steel tubing
•
No. 65S is especially designed for stainless steel tubing; includes
six individual bearings and cutter wheel to make stainless cutting
easier
Item #
RI50767
Item #
RI50812
Item # Close Quarters AUTOFEED™ Cutter
RI86127 Close Quarters Quick-Feed Cutter
RI32573 Close Quarters Quick-Feed Cutter
with Ratchet Handle
Item # Model No.
Desc.
Capacity (in.)
RI40617
101
Close Quarters Cutter
¹⁄₄
- 1
¹⁄₈
RI32975
103
Close Quarters Cutter
¹⁄₈
-
⁵⁄₈
RI32985
104
Close Quarters Cutter
³⁄₁₆
-
¹⁵⁄₁₆
RI97787
117
Close Quarters
AUTOFEED™ Cutter
³⁄₁₆
-
⁵⁄₁₆
Item # Model No.
Desc.
Std. Wheel
Capacity
(in.)
RI32910
10
Tubing and
Conduit Cutter
F-158
¹⁄₈
-1
RI32915
10
Above w/H-D
Wheel
E-1240
¹⁄₈
-1
RI32920
15
Tubing and
Conduit Cutter
F-158
³⁄₁₆
-1
¹⁄₈
RI32925
15
Above w/H-D
Wheel
F-58
³⁄₁₆
-1
¹⁄₈
RI32930
20
Tubing and
Conduit Cutter
F-158
⁵⁄₈
-2
¹⁄₈
RI32935
20
Above w/H-D
Wheel
E-1240
⁵⁄₈
-2
¹⁄₈
RI32950
30
Above w/H-D
Wheel
E-2191
1-3
¹⁄₈
