151
RIDGE TOOL CO.
Pipe Die Set
National Pipe Taper
•
Listed below are pipe dies for use
in Universal Die Heads
•
Use With 504A, 711, 713, 811A, 815A, 816, 817 and 842
RIDGE TOOL CO.
Bolt Dies
•
Bolt dies for universal die heads (nos.
504A, 711, 811A, 815A, 816, 817 and
911 die heads)
•
(UNC) RH high-speed
RIDGE TOOL CO.
Nipple Chuck Kits
•
Holds short or close nipples for
threading
•
Holds studs for threading
•
For use with 300 power drive, 300
compact, 535 and 1822 (with
adapter kit) and 1224 threading
machines
•
Standard nipple chuck includes insert and 5 adapters: 1/2", 3/4",
1", 1-1/4" and 1-1/2" (nipple chuck body serves as 2" adapter)
RIDGE TOOL CO.
Power Driver
Roll Groover
Model No. 916
•
Ridgid Model 916 Roll Groover is
the most durable and
mechanically efficient lightweight
portable unit available
•
Cam-type feed actuation-only
minimum effort required by
operator
•
Capacity:
•
1-1/4”-6” Sch. 10 steel
•
1-1/4”-3” Sch. 40 steel
Standard Equipment:
•
One (1) 1-1/4” - 6” Roll groove set for steel
RIDGE TOOL CO.
Combo Roll Groover
Model No. 975
The new, Model 975 Combo Roll
Groover is two tools in one! Like other
Ridgid® groovers, the 975 mounts on the
Ridgid® 300 Power Drive for machine
grooving jobs, but it is also designed to
manually groove in-place pipe.
•
Pipe Capacity:1-1/4" – 6" Schedule 10
and Schedule 40 Steel, Aluminum,
and PVC Pipe; 1-1/4" – 6" Schedule 10, 1-1/4" – 2" Schedule 40
Stainless Steel Pipe,
1-1/2" – 4" Schedule 80 PVC Pipe; With Roll Change 2" – 8"
Copper Tube (Type K, L, M, and DWV)
RIDGE TOOL CO.
Hydraulic Roll Groover
Model No. 918
The Ridgid model 918 hydraulic roll
groover features a powerful 15 ton
hydraulic ram in a compact, easy to
transport unit. With one man set-up
and operation, the 918 is the ideal
groover for job-site requirements.
The 918 adapts quickly to Ridgid 300
power drive, 535, 1822, or 1224
threading machines. The 918 is
capable of grooving up to 12" schedule 10 and 8" schedule 40
standard wall pipes. Roll set changeout is accomplished in seconds.
Specifications:
•
Capacity: 1" - 12" schedule 10 steel
•
1"-8" schedule 40 steel
•
2"-6" cooper (types K, L, M, DWV)
•
2-1/2" - 6" schedule 80 PVC
Standard equipment:
•
One (1) 2" - 6" schedule 10/40 roll set
•
One (1) 8" - 12" schedule 10(8" schedule 40) roll set
Item # Nominal Pipe Size-Threads per Inch (in.)
Alloy RH
RI47740
¹⁄₄
-
³⁄₈
-18
RI47745
¹⁄₂
-
³⁄₄
-14
RI47750
1-2-11
¹⁄₂
High Speed RH
RI47755
¹⁄₈
-27
RI47760
¹⁄₄
-
³⁄₈
-18
RI47765
¹⁄₂
-
³⁄₄
-14
RI47770
1-2-11
¹⁄₂
H. S. For Stainless Steel RH
RI47780
¹⁄₄
-
³⁄₈
-18
RI47785
¹⁄₂
-
³⁄₄
-14
RI47790
1-2-11
¹⁄₂
Item # Rod Size- TPI (in.)
RI48225
³⁄₈
- 16
RI48235
¹⁄₂
- 13
RI48245
⁵⁄₈
- 11
RI48250
³⁄₄
- 10
RI48255
⁷⁄₈
- 9
RI48260
1 - 8
RI48270
1
¹⁄₄
- 7
Item # Model No.
Desc.
RI51005
819
NPT Nipple Chuck
¹⁄₂
in. - 2 in.
Item #
Desc.
RI45007 Roll Groover for 300 Power Drive
Item #
RI25638
Item #
Desc.
RI48297 918 Roll Groover W/300 Power Drive Mount Kit
