www.edgecs.com
318
Safety & Security
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
MILLER BY HONEYWELL
Harness Accessories
Revolution™
The PivotLink Connection provides
an attachment point for a multitude of
accessories and individual tool
pouches with an innovative design
that accommodates
•
Pouches, tool holders, cell phones, water bottles and more
•
A tool belt that easily attaches and detaches – distributing weight
across the hips and shoulders for a more comfortable fit and
greater mobility
•
Universal attachment clips that fit on your existing accessories or
tool rig and easily attach/detach
MILLER BY HONEYWELL
Non-Stretch Harness
•
Rated to 400 lbs. capacity
•
Self-contained label pack encapsulates labels
minimizing damage and loss; integrated and
oversized pull-free lanyard rings
•
Bright webbing colors are easily visible
enhancing compliance and inspection
•
Back D-ring
MILLER BY HONEYWELL
Contractor Harness
Non-Stretch
650CN Series
•
Specifically designed for use in construction with
the unique combination back D-ring pad/shoulder
pads that minimize discomfort/stress around the
neck and shoulders when using a tool belt
•
All harnesses come equipped with a back D-ring
and sub-pelvic strap
•
Materials:
•
Webbing: 1 æ” Polyester
•
Elastic Keepers: Polyester, Nylon, Lycra
•
Thread: 6 cord bonded 3 strand polyester thread
•
D-ring: Clear Chromate Finished Carbon Steel
•
Hardware:
•
Brass Grommets
•
All hardware meets ASTM (50) fifty-hour salt spray test
requirements
•
Max. Working Load: 400 lbs
•
Meets OSHA 1910.66, 1926.502 (d), ANSI A10.32, Z359
-2007 and CSA Z259.10-06 specifications
•
Note: For front D-ring vest-style option, add “FD” to the
corresponding harness model number (Ex. 650CNFD-BP/UGN).
Model numbers listed are for universal size. Harnesses are also
available in small/medium and XXlarge, by replacing the “U” in the
model number with “S/M” or “XXL” (Ex. 650CN-BP/XXLGN or
650CN-BP/S/MGN)
MILLER BY HONEYWELL
Non-Stretch Harness
HP™
•
Rated to 400 lbs. capacity
•
Self-contained label pack encapsulates labels
minimizing damage and loss; integrated and
oversized pull-free lanyard rings
•
Comfort-touch back D-ring pad is designed with
woven, breathable material for cooler extended
wear comfort; orients harness for quick tangle
free donning
•
Bright webbing make the harnesses readily visi-
ble and easy to inspect
•
Polyester 1” webbing
•
Side and back D-rings
•
Pull-up adjustment style
MILLER BY HONEYWELL
Titan™ Non-Stretch Harness
•
Rated to 400 lbs.
•
Sliding back D-ring
•
Two pull-free lanyard rings
•
Non-stretch
Item #
Desc.
MYRIA-T1 Mini Cell Phone Holder w/Snap-On Connector
MYRIA-T2
Regular Cell Phone/Jobsite Radio Holder,
w/Snap-On Connector
MYRIA-T3
Water Bottle Holder, 1 Qt.
MYRIA-T4 Large Open Bolt & Bull Pin Bag w/Quick-Release
Tool Snap
MYRIA-T5
Medium Open Bolt & Bull Pin Bag
MYRIA-T6
2 Pocket Nail & Tool Pouch
MYRIA-T7 Large Multi-Pouch Tool Bag w/2 Steel Hammer
Loops
MYRIA-T8
Padded Hammer Loop
MYRIA-T9
Open End Pliers & Tool Holder
MYRIA-T10
Zippered Cylindrical Utility Pouch
MYRIA-T11
Leather Tool Pouch
Pivot Link Connection Kits
MYRIA-K2
Regular Cell Phone/Jobsite Radio Holder
w/Snap-On Connector, Water Bottle Holder,L arge
Multi-Pouch Tool Bag w/2 Steel Hammer Loops
MYRIA-R2 Belt w/Pad and PivotLink Attachments, 5 Accessory
Connectors, Large Multi-Pouch Tool Bag w/2 Steel
Hammer Loops, 2 Pocket Nail & Tool Pouch,
Zippered Cylindrical Utility Pouch
MYRIA-R4 Belt w/Pad and PivotLink Attachments, 5 Accessory
Connectors, 2 Large Open Bolt & Bull Pin Bags,
Padded Hammer Loop
Item #
Size
MY751L/XL L/XL
Item #
Size Side D-Rings
MY650CN-BP/UGN Universal
No
MY650CN-BDP/UGN Universal
Yes
Item #
Size
MY650T-58 Universal
Item #
MYT4007
