MILLER BY HONEYWELL
Safety Lifelines
Rope:
•
5/8” nylon
•
A standard four-tuck splice is hand-
crafted on each end, the ends of the rope are seared to prevent
fraying; the last splice is treated with a nylon-based stiffening
agent to prevent the splice from unraveling
Thimbles:
•
A round, black plastic thimble is used in each lanyard eye to
protect the eye from wear
Technical:
•
Max. Working Load: 310 lbs. (141 kg)
•
Minimum Tensile: 5,000 lbs. (22kN)
MILLER BY HONEYWELL
Safety Lifelines
Materials:
•
Rope: Polypropylene/Polyester
•
Snap Hook: Clear Zinc Chromate
Plated Forged Alloy Steel
•
Proof tested to 3,600 lbs.
Technical:
•
Rope Diameter: 5/8”
•
Min. Tensile Strength: 5000 lbs.
MILLER BY HONEYWELL
Carabiners
•
Carabiners with spring loaded keepers are
used as anchorage connectors; has a 1”
gate opening and is plated to resist rust
and corrosion
•
400 lb. maximum capacity
MILLER BY HONEYWELL
Rebar
Positioning Assembly
•
Rebar chain assembly used for positioning
•
Hardware: Steel, Zinc Plated
•
Locking Snap Hooks: 3/4” gate opening
•
Locking Rebar Hooks: 2-1/2” gate opening
MILLER BY HONEYWELL
Cross-Arm
Anchorage Connector
•
Web straps wrap around I-beams and
other structures
•
Attaches with 2” D-ring that slips through
3” D-ring to form secure attachment
•
6 ft. length
•
400 lbs. maximum capacity
MILLER BY HONEYWELL
Cable
Anchorage Connector
•
Creates a quick and easy secure
point of attachment; simply wrap the
cable around an I-beam or other
structure capable of withstanding
5,000 lbs. and connect the captive
eye carabiner to the thimble at the
opposite end of the cable
•
Constructed of 1/4” vinyl-coated, galvanized wire rope, 6 ft. length
•
Forged steel, auto-lock, captive eye carabiner with 1” gate opening
•
Forged steel 3” O-ring
MILLER BY HONEYWELL
Wire Hook Anchor
Stainless steel wire hook connects to various
approved anchorages including railings, small
I-beams, angle iron and scaffolding. Squeeze
the spring-loaded hook and slip the large
opening over the approved structure.
•
Max. Capacity: 400 lbs. (181.4 kg)
MILLER BY HONEYWELL
Permanent Roof Anchor
•
Ideal for new construction or as a
retrofit on roofs with asphalt, shake
or tile roofing materials
•
Only the permanent D-ring(s)/
anchor is exposed, providing a
quick, safe fall arrest connection
point(s)
•
Stainless steel body construction,
zinc-plated steel D-ring(s) resist
corrosion for long service life
•
Complete with 8, 16d nails
Item #
Length (ft.)
MY195R-2-25
25
MY195R-2-50
50
Item # Length (ft.)
MY300L-2
25
MY300L-5
50
MY300L-7
75
MY300L-10
100
Item #
MY17D-1
Item #
MY6756RS
Item #
MY8183
Item #
MY8187V
Item #
MY470
Item #
MYRA40
