ANVIL
Rod Attachments
Figure 290 Weldless Eye Nut
•
Size Range: 3⁄8" through 2-1⁄2"
•
Material: Forged steel
•
Finish: Plain or Galvanized
•
For use on high temperature piping installations
•
Complies with Federal Specification A-A-1192A (Type 17),
WW-H-171-E (Type 17), ANSI/MSS SP-69 and MSS SP-58 (Type 17)
•
Features: Supports loads equal to the full limitation of the hanger rod
•
Provides flexible connection when used with straight thread rod
•
Specify rod size, figure number, name and finish. If other than standard combination of eye nut number and rod size,
specify eye nut number and special rod tapping size
•
Note: The acceptability of galvanized coatings at temperatures above 450°F is at the discretion of the end user
•
Larger eye nuts featuring smaller rod sizes are commonly available
•
Left hand tap is also available. Specify figure 290L
ANVIL
Pipe Supports
Figure 191 Adjustable Pipe Stanchion Saddle With U-Bolt
•
Size Range: 2" through 12"
•
Material: Carbon steel
•
Finish: Plain or Galvanized
•
Stanchion type support where vertical adjustment is required, plus the additional stability provided by
U-bolt attachment to stationary pipe
•
Complies with Federal Specification A-A-1192A (Type 37), ANSI/MSS SP-69 and MSS SP-58 (Type 37)
•
Specify pipe size, figure number, name and finish
Item #
Rod Size A
(in.)
Max Load For Service
Temp 650°F/750°F
Weigh
t (lbs.) B (in.) C (in.) D (in.)
E (in.) F (in.)
G (in.)
Eye Nut
Number
AV290-3/8
³⁄₈
730/572
0.63 1
¹⁄₂
1
³⁄₁₆
¹⁄₂
2
1
³⁄₈
¹¹⁄₁₆
1
AV290-1/2
¹⁄₂
1,350/1,057
0.63 1
¹⁄₂
1
³⁄₁₆
¹⁄₂
2
1
³⁄₈
¹¹⁄₁₆
1
AV290-5/8
⁵⁄₈
2,160/1,692
0.62 1
¹⁄₂
1
³⁄₁₆
¹⁄₂
2
1
³⁄₈
¹¹⁄₁₆
1
AV290-3/4
³⁄₄
3,230/2,530
0.60 1
¹⁄₂
1
³⁄₁₆
¹⁄₂
2
1
³⁄₈
¹¹⁄₁₆
1
AV290-7/8
⁷⁄₈
4,480/3,508
1.70 2 1
¹¹⁄₁₆
³⁄₄
2
⁵⁄₈
1
¹⁵⁄₁₆
1
2
AV290-1
1
5,900/4,620
1.70 2 1
¹¹⁄₁₆
³⁄₄
2
⁵⁄₈
1
¹⁵⁄₁₆
1
2
AV290-1-1/4
1
¹⁄₄
9,500/7,440
3.60 2
¹⁄₂
1
¹³⁄₁₆
1
3
³⁄₈
2
³⁄₈
1
¹⁄₄
3
AV290-1-1/2
1
¹⁄₂
13,800/10,807
3.50 2
¹⁄₂
1
¹³⁄₁₆
1
3
³⁄₈
2
³⁄₈
1
¹⁄₄
3
AV290-1-3/4
1
³⁄₄
18,600/14,656
16.40 4
4 1[1[/2]
6
¹⁄₄
4
2
¹⁄₄
4
AV290-2
2
24,600/19,265
15.90 4
4 1[1[/2]
6
¹⁄₄
4
2
¹⁄₄
4
AV290-2-1/4
2
¹⁄₄
32,300/25,295
15.40 4
4 1[1[/2]
6
¹⁄₄
4
2
¹⁄₄
4
AV290-2-1/2
2
¹⁄₂
39,800/31,169
14.90 4
4 1[1[/2]
6
¹⁄₄
4
2
¹⁄₄
4
Item # Pipe Size (in.) Rod Size A (in.)
C (in.)
E (in.)
G (in.)
Weight (lbs.)
AV191-2
2
⁵⁄₈
2
¹¹⁄₁₆
9
⁷⁄₁₆
¹⁄₄
x1
1.2
AV191-2-1/2
2
¹⁄₂
⁵⁄₈
3
⁵⁄₁₆
9
¹¹⁄₁₆
¹⁄₄
x1
1.4
AV191-3
3
⁵⁄₈
3
¹⁵⁄₁₆
10
¹⁄₄
x1
1.6
AV191-3-1/2
3
¹⁄₂
⁵⁄₈
4
⁷⁄₁₆
10
¹⁄₄
¹⁄₄
x1
2.6
AV191-4
4
⁷⁄₈
5
¹⁄₄
10
¹⁄₂
¹⁄₄
x1
¹⁄₄
3.0
AV191-5
5
⁷⁄₈
6
¹⁄₈
11
¹⁄₄
x1
¹⁄₄
3.2
AV191-6
6
1
7
¹⁄₄
11
¹¹⁄₁₆
³⁄₈
x1
¹⁄₂
4.9
AV191-8
8
1
9
³⁄₈
12
¹¹⁄₁₆
³⁄₈
x1
¹⁄₂
6.2
AV191-10
10
1
¹⁄₄
11
¹⁄₂
13
⁷⁄₈
¹⁄₂
x2
10.5
AV191-12
12
1
¹⁄₄
13
¹⁄₂
14
⁷⁄₈
¹⁄₂
x2
11.8
