535
ERICO/CADDY
Fixed Strut Support
Caddy®
•
Provide fixed height mounting plat-
form 4” or 6.4” off roof surface and
10” or 16” usable strut length
•
Maximum recommended load up to
1500 lbs
•
Hot-dipped galvanized finish provide superior corrosion protection
ERICO/CADDY
Adjustable Height Strut
Support
Caddy®
•
Allow elevation change up to 17” off roof
surface
•
10” or 16” usable strut length
•
Maximum recommended load up to 1500
lbs
•
Hot-dipped galvanized finish provides superior corrosion protec-
tion
ERICO/CADDY
Pyramid Rooftop Pipe Support
Caddy®
CADDY® PYRAMID RPS H Series Support System is a fast and economical solution for a variety of rooftop
applications. It provides superior support for pipe, conduit, ductwork, cable tray, or any combination of these
without causing damage to the rooftop membrane.
•
Designed to offer superior protection to rooftop membrane
•
Highly engineered design of the base uniformly distributes load
•
Continuous bottom surface mitigates unwanted stress concentrations
•
Ideal for pipework, duct, conduit, cable tray, or any combination of these
•
Base is made from recycled, UV stabilized engineered thermoplastic
•
Integral foam pad provides gentle interface for all roof types
•
Accepts standard strut channels
•
Mounting hardware pre-installed in bases
•
Hot-dip galvanized hardware
OREGON WIRE PRODUCTS
Acoustical Ceiling Wire
•
12 gauge acoustical ceiling suspension
wires for drop ceilings
•
Other gauges available
•
Call to specify length
•
Call to inquire about other loop or anchor
styles
GRIPPLE
Trapeze No.2
•
Ideal for fast suspension of rectangular duct,
chilled beams, cable tray, etc
•
Tapered design - accommodates all slots sizes in
strut
•
Discreet - fits completely inside the strut channel
•
Ability to pre-fit onto strut channel on the ground to
minimize time working at height
•
Release Pin allows rapid height adjustment
•
Load rated at 100 lbs per hanger with a 5:1 safety
factor
•
EF
(End Fixing): LG (loop), TG (toggle), TQG (1/4” toggle), HG
(hook), SQG (1/4” stud), SQ2G (1/4” stud, 2” length), EYQG
(Eyelet), EY90QG (90° 1/4” eyelet), BQG (1/4” barrel) or B3/8G (3/
8” barrel)
•
L
(Length): 5’, 10’, 15’, 20’ or 30’
Item #
Height (in.)
Desc.
CARPS360400
4”
12
¹⁄₂
” x 10” footprint
Item #
CARPS360405
Item #
Description
Height
(in.)
Strut Size
(in.)
Hardware
Kit Included
Rooftoop
Interface
Static Load
(lbs.)
Standard
Package Qty.
CARPS360422 Rps Post Base, 12x12, Foam 4.6 1
¹⁄₄
x1
¹⁄₄
No
Foam 750
1
CARPS360423 Rps Post Base, 12x12, Rubber
4.6 1
¹⁄₄
x1
¹⁄₄
No
Rubber
750
1
Item #
Ramset SDC125 1-1/4” Pin and Angle
HFPTXXXX
Straightwire
HFSWXXXX
Item #
GPTZ2-
EF
-
L
-LFT
