LINDAPTER®
Type F9
Steel Clamp
•
Flange clamp for connecting|
parallel running sections with flanges of same width
•
Can be used with bolts or alternatively with threaded rod
•
Not suitable for tapered flanges
•
Malleable iron; Bright iron plated or hot dip galvanized finish
•
Available without bolt (use NB suffix)
•
Loads are subject to application, please contact Edge for more information
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE FC
Flush Clamp
•
The Flush Clamp is a Girder Clamp System without the need of a location plate
•
Suitable for connecting beams of varying widths and thicknesses
•
Suitable for flanges up to 10° slope
•
Forged Steel
•
Bright Zinc plated plus JS500 finish
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE HW/HC
Steel Clamp
•
For vertical suspension on angled surface of up to 10° swing either side of the vertical
•
Hemispherical washer (HW) can be used without the cup
•
Malleable Iron
•
Bright Zinc plated or hot dip galvanized finish
•
Contact Edge for detailed specs and design data
Item #
Bolt Size Z Safe Working Loads (5:1 Factor Of Safety) Tensile/1 Bolt (lbs.)
Torque (ft./lbs.)
LDLF9037WB
³⁄₈
”
440
15
LDLF9050WB
¹⁄₂
”
630
29
LDLF9062WB
⁵⁄₈
”
1,260
69
LDLF9075WB
³⁄₄
”
1,880
131
LDLF9100WB
1”
3,147
173
Item #
Special
Bolt Size
Z
Safe Working Loads
(5:1 Factor of Safety)
Tensile/4 Bolts (lbs.)
Safe Working Loads
(5:1 Factor of Safety)
Frictional/4 Bolts (lbs.)
Torque
(ft.lb.)
Clamping Range
Flange Thickness V
Clamping Range
Flange Width b
T B
LDLFCM16
⁵⁄₈
”
6,744
1,686
108
³⁄₁₆
”-
³⁄₄
”
3”-7”
⁷⁄₈
”-1
¹⁄₁₆
” 12”
Item # Rod Size Z Washer X Washer W1 Dimensions Cup Y Dimensions Cup W2 Washer & Cup R Washer & Cup L
Washer
LDLHW037
³⁄₈
”
1”
¹⁄₂
”
¹⁄₂
”
⁹⁄₁₆
”
LDLHW050
¹⁄₂
”
1
¹⁄₈
”
¹⁄₂
”
⁹⁄₁₆
”
⁵⁄₈
”
LDLHW062
⁵⁄₈
”
1
³⁄₈
”
⁵⁄₈
”
¹¹⁄₁₆
”
³⁄₄
”
LDLHW075
³⁄₄
”
1
³⁄₄
”
³⁄₄
”
⁷⁄₈
”
¹⁵⁄₁₆
”
LDLHW100
1”
2
¹⁄₄
”
1”
1
¹⁄₈
”
1
¹⁄₄
”
Cup
LDLHC037
³⁄₈
”
1
¹⁄₄
”
¹⁄₂
”
¹⁄₂
”
⁹⁄₁₆
”
LDLHC050
¹⁄₂
”
1
³⁄₈
”
¹⁄₂
”
⁹⁄₁₆
”
⁵⁄₈
”
LDLHC062
⁵⁄₈
”
1
⁵⁄₈
”
⁵⁄₈
”
¹¹⁄₁₆
”
³⁄₄
”
LDLHC075
³⁄₄
”
2
¹⁄₈
”
³⁄₄
”
⁷⁄₈
”
¹⁵⁄₁₆
”
LDLHC100
1”
2
⁵⁄₈
”
1”
1
¹⁄₈
”
1
¹⁄₄
”
