LINDAPTER®
TYPE A
Steel Clamp
•
Type A clamp with recessed top to hold the bolt head captive while the nut is tightened. The skirt prevents the clamp
rotating during installation
•
Suitable for parallel flanges, and tapered flanges up to 8°
•
The tail must be chosen to suit the thickness of the flange being gripped
•
Specify the tail length as either Short, Medium or Long by adding ‘S’, ‘M’ or ‘L’ to the end of the item #
•
Malleable iron; Bright zinc plated or hot dip galvanized finish
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE B
Steel Clamp
•
Type B clamp with flat top which allows the bolt head or nut to be rotated
•
Suitable for use with bolts, studs, tie rods, J-bolts, parallel flanges, and tapered flanges up to 8°
•
The tail must be chosen to suit the thickness of the flange being gripped
•
Specify the tail length as either Short, Medium or Long by adding ‘S’, ‘M’ or ‘L’ to the end of the item #
•
Malleable iron; Bright zinc plated or hot dip galvanized finish
•
Contact Edge for detailed specs and design data
LINDAPTER®
TYPE CW
Steel Clamp Accessory
•
Packing used to adjust the tail length of the clamp to meet differing beam flange thicknesses
•
Mild steel; Bright zinc or hot dip galvanized finish
•
For use with Type A or B Clamps
•
Contact Edge for detailed specs and design data
Item #
Grade 5
Bolt Size Z
Safe Working Loads
(5:1 Factor Of Safety) Tensile/1 Bolt (lbs.)
Safe Working Loads
(5:1 Factor Of Safety) Frictional/2 Bolts (lbs.)
Torque
(ft./ lbs.)
LDLA037
³⁄₈
”
330
-
15
LDLA050
¹⁄₂
”
1,300
157
50
LDLA062
⁵⁄₈
”
1,640
337
108
LDLA075
³⁄₄
”
3,300
674
210
LDLA100
1”
4,430
1,012
362
Item #
Grade 5
Bolt Size Z
Safe Working Loads
(5:1 Factor Of Safety) Tensile/1 Bolt (lbs.)
Safe Working Loads
(5:1 Factor Of Safety) Frictional/2 Bolts (lbs.)
Torque
(ft./ lbs.)
LDLB037
³⁄₈
”
330
-
15
LDLB050
¹⁄₂
”
1,300
157
50
LDLB062
⁵⁄₈
”
1,640
337
108
LDLB075
³⁄₄
”
3,300
674
210
LDLB100
1”
4,430
1,012
362
Item # Bolt Size Z
Y
X
T
Width
LDLCW037
³⁄₈
”
³⁄₁₆
”
⁹⁄₁₆
”
¹⁄₁₆
”
1”
LDLCW050
¹⁄₂
”
¹⁄₄
”
³⁄₄
”
¹⁄₈
”
1
¹⁄₄
”
LDLCW062
⁵⁄₈
”
⁵⁄₁₆
”
¹¹⁄₁₆
”
¹⁄₈
”
1
¹⁄₂
”
LDLCW075
³⁄₄
”
³⁄₈
”
⁷⁄₈
”
³⁄₁₆
”
1
³⁄₄
”
LDLCW100
1”
¹⁄₂
”
1
¹⁄₈
”
³⁄₁₆
”
2
¹⁄₄
”
