SPECIFIED TECHNOLOGIES
Fire Barrier Composite Sheets
•
Lightweight for easy handling and fabrication and
less hanging weight on walls
•
Easy to cut using sheet metal tools
•
Highly intumescent – expands up to 15X
•
Hole Reduction – Used in conjunction with other
SpecSeal or EZ-Path® Products for reducing large
openings
SPECIFIED TECHNOLOGIES
Firestop Sleeve Kit
SpecSeal® Ready Sleeve™
•
Seals off the path of fire, smoke and
superheated gases while providing
support and protection for electrical,
telephone, and data cables
•
Economical – Significant material and
labor savings vs. field fabrication
•
No External Firestop Seal Required –
Factory supplied intumescent firestop
gasket eliminates the need to seal the circumference of the steel
sleeve at its egress from each side of barrier
•
UL® Classified and Code Compliant – Each kit designed to
provide up to a 2 hour F Rating in accordance with UL® System
requirements; assures code compliance every time
•
For Rated and Non-Rated Barriers – Putty seal impedes the
passage of fire, smoke, superheated gases, and particulate dust,
and minimizes noise transmission
SPECIFIED TECHNOLOGIES
Firestop Sleeve Kit
SpecSeal® Ready™ Split Sleeve
•
The only UL® Classified Firestop
Sleeve for use in oversize openings
•
Smooth cable entry — Unique rolled lip
eliminates potential sharp edges and
the need for conduit
bushings
•
Sturdy, lightweight — At half the weight of threaded products, and
with fewer parts required
•
Cable management — Inspector-friendly wall labels included with
every kit
•
UL Tested and Classified in accordance with ASTM E 814
(UL 1479) with F Ratings up to 4 hours
SPECIFIED TECHNOLOGIES
Firestop Pillows
SpecSeal®
•
Intumescent - expands in all
directions for a tough, tight seal
•
Reinstallable - for easy retrofitting of
cables
•
Heat-sealed poly bag protects core
and makes pillows slide in and out easier
•
Monolithic encapsulated core - no loose fill, tougher, more resilient
•
Superior air leakage rating
•
UL, cUL classified and FM approved
•
Meets the exacting criteria of ASTM E814 (UL1479).
SPECIFIED TECHNOLOGIES
Cable Pathway
and Firestop
Series 22
EZ-Path™
•
Designed for new or existing cable installations through walls
(only) up to 9” thick and holds up to 24 CAT 5E cables
•
Pathway can be mounted as a single unit in either a 2” round or a
1-1/2” x 1-1/2” square opening
•
Height x Width: 1-1/2” x 1-1/2”
•
Length: 10-1/2”
•
Fire rated in walls up to 4 hrs.
SPECIFIED TECHNOLOGIES
Cable Pathway
and Firestop
Series 33 Seven Gang Kit
EZ-Path™
•
Seven gang kit designed to allow seven Series 33 Pathways to be
installed in a 3” x 21” opening
•
Attachment plates can be fastened to studs spaced 24” O.C. as
the wall is being built or they can be installed in finished walls
Item #
Size (in.)
STICS1628 16 x 28
STICS2436 24 x 36
STICS3641 36 x 41
Item #
Desc.
STIFS100 1” sleeve
STIFS200 2” sleeve
STIFS400 4” sleeve
Item #
Size
(in.)
Plate
Diameter (in.)
Min.
Opening (in.)
Max.
Opening (in.)
STIFSR100 1
3x3
1.16
2.25
STIFSR200 2
4.5x4.5
2.38
4.0
STIFSR400 4
8x8
4.5
6.0
Item # Dimension (in.) Std. Pkg. Qty.
STISSB14 1 x 4 x 9
20
STISSB24 2 x 4 x 9
10
STISSB26 2 x 6 x 9
22
STISSB36 3 x 6 x 9
16
Item #
Desc.
STIEZD22 Device Kit, (2) Wall Plates and (1) Device
Item #
STIEZDP733GK
Make sure to use
an approved UL
firestop system
