Firestop
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
SPECIFIED TECHNOLOGIES
Cable Pathway and
Firestop Devices
Series 33
EZ-Path™
•
No firestopping required - always
firestopped
•
Self-contained firestop
system - automatically adjusts to
cable loads
•
Easily moves, adds, and changes
•
The compact square design (3" x 3" x 10-1/2" long) provides
greater cable loading than a conventional 4" sleeve, cables can be
added or changed without the need to remove and re-install
firestopping materials
•
Offers a clean, professional, engineered appearance; the device is
colored safety orange and comes with wall labels for easy
identification
•
Splits apart for "old work"
•
UL® classified up to 4 hours and FM approved in accordance with
ASTM E814 (UL1479)
•
Fire rated in walls and floors up to 4 hrs.
•
Ask about other kits and adapters
•
Ask about ganging multiple devices together
SPECIFIED TECHNOLOGIES
Cable Pathway
and Firestop
Series 44 Modular Floor
grid Sytem
EZ-Path®
•
The EZ-Path Modular Floor Grid
system can handle literally
thousands of cables
•
Modular Floor Grid Systems
utilize the high volume, EZ-Path 44 Series Pathways installed in
banks of four to provide your cabling systems with room to grow
•
Sturdy steel grids mount one, two or four banks of pathways in
built-in slots for a total of up to sixteen pathways through a single
floor opening. A single bank Floor Grid comes complete with
Pathways. Multi-bank Modular Floor Grids are installed with
firestop panels sealing each slot. As additional cable capacity is
required, firestop panels are removed and pathway modules
containing four pathways are installed in each slot
•
Ask for help with your configuration
•
Many options available
SPECIFIED TECHNOLOGIES
Cable Pathway and
Firestop Devices
Series 44
EZ-Path®
•
Designed for new or existing cable
installations up to 10” thick through walls or floors
•
The EZ-Path® Series 44 pathway holds up to 240 CAT 5E cables
•
Pathways can be ganged for additional capacity
•
Height x Width: 4” x 4-5/8”
•
Length: 14”
•
Can be ganged up to 5 in walls and up to 16 in floors
•
Fire rated in walls up to 4 hrs.
•
Fire rated in floors up to 4 hrs.
SPECIFIED TECHNOLOGIES
Ready® Firestop Grommet
•
Single Cable Penetrations can be
time consuming, expensive, and
messy. Now there is a new
solution from the cabling
innovators at STI. Ready Firestop
Grommets make membrane and
through-penetrations through
rated gypsum board walls a snap.
Just drill a hole, run your cable,
snap the grommet around the
cable, and press it into the wall.
Use a single grommet for single
sided (membrane) penetrations,
or drill a hole through both sides
of the wall and install grommets back-to back for through
penetrations
•
Ready Firestop Grommet is molded from a premium grade
plenum-rated polymer. A soft foam inner core conforms to the
cable to form a tight seal. The cable is smoke-sealed and
firestopped in just minutes with no sleeve, and no sealant or putty
required
•
Quick to install - 2 piece grommet snaps together for an easy
installation
•
Economical - Eliminates Sleeves and the need for putty or sealant
•
Split design - Can be used with previously installed cables
•
Made with Ultem® premium, plenum-grade material - Exceptional
flame & heat resistance
•
Low voltage cables up to .027 in. O.D.
•
1 & 2 Hr rated gypsum board walls
•
Single membrane or through-penetrations
Ready Firestop Grommets were tested to meet the exacting criteria of
ASTM E814 (UL1479) and CAN/ULC S115. Tested systems provide
up to 2 hr. fire ratings for single cable penetrations in gypsum
board/stud wall assemblies
Item #
Desc.
STIEZD33FWS
Device
STIEZDP33FWS Device Kit, (2) Wall Plates and (1) Device
Item #
Desc.
STIEZDG444 Single Slot Grid, Complete With Grid and Four
Pathways
STIEZG844 Dual Slot Grid Only, 8 Pathway Capacity, With
Firestop Panels to Seal Unused Slots
STIEZG1644 Four Slot Grid Only, 16 Pathway Capacity, With
Firestop Panels to Seal Unused Slots
STIEZD444MB Four Pathways and Hanger Brackets for use in
EZG844 and EZG1644
Item #
Desc.
STIEZD44 Device Only
Item #
Color
Overall Length Req. Opening
STIRFG1
Red
1
⁵⁄₈
”
⁹⁄₁₆
”
