CHICAGO PNEUMATIC TOOL CO.
Chipping Hammers
CPCP 0012:
•
Since the CPCP 0012 is light and has medium hitting power, it is very easy to handle and control for more precise jobs
•
Typical applications include alteration work, hole making and trimming
CPCP 4123:
•
The most popular chipping hammer; the CPCP 4123 is used for a wide variety of construction and industrial applications, from
light to medium chipping to heavy cutting; choose the cylinder size that best suits your particular application
•
Classic simplate valve; heat treated cylinder; now with spline lock instead of clip locking mechanism
CPCP 4125:
•
Extra features of the CPCP 4125 make it more suitable for tough construction and industrial applications, including foundries,
shipyards, refineries, or fabrication shops
•
Unique ring valve as standard for harder blow in tough applications or dirty environments; chrome plated cylinder for extra durability; spline
locking to prevent loosening of handle or cylinder
CPCP 4123 & CPCP 4125:
•
Powerful, yet compact and lightweight; rugged construction, hardened steel cylinder and handle; teasing throttle for precise control; open grip
handle with self closing outside trigger
•
Available in 2”, 3” or 4” cylinder stroke versions
Choice of bushing:
•
.680” Round chisel rotates freely or .580” Hex prevents chisel rotation
CPCP 4130:
•
It is used for medium-duty to heavy-duty chipping, cutting and trimming operations; the four bolt handle provides higher air flow and durability
•
Locking mechanism with four high-strength 1/2” bolts
•
“D” handle with outside trigger and extra safety mechanism
•
Muffler assembly as standard
•
Available in 3” or 4” cylinder stroke versions
Choice of bushing:
•
.680” Round chisel rotates freely or .580” Hex prevents chisel rotation
CPCP 4132:
•
A durable 4-bolt chipping hammer with inside trigger and standard retainer; available in two cylinder sizes to suite your particular application
Item #
Old Model Name
Weight
(lbs.)
Cylinder
Stroke
Length
(in.)
Blows Per
Minute (bpm)
Air Consump.
(CFM)
Muffler Included
As Standard
Chuck Size
(in.)
CPCP 0012 2BR
12
2
16
2600
20
yes
.680” Rnd
CPCP 0012 2H
12
2
16
2600
20
yes
.580” Hex
CPCP 4123 2R CPCP 4123 PYRA 13
2
12
⁷⁄₈
2400
25
-
.680” Rnd
CPCP 4123 2H CPCP 4123 PYRE 13
2
12
⁷⁄₈
2400
25
-
.580” Hex
CPCP 4123 3R CPCP 4123 PYSA 15
3
14
⁷⁄₈
1920
26
-
.680” Rnd
CPCP 4123 3H CPCP 4123 PYSE 15
3
14
⁷⁄₈
1920
26
-
.580” Hex
CPCP 4123 4R CPCP 4123 PYTA 16
4
15
¹⁄₂
1500
27
-
.680” Rnd
CPCP 4123 4H CPCP 4123 PYTE 16
4
15
¹⁄₂
1500
27
-
.580” Hex
CPCP 4125 2R CPCP 4125 PALA 13
2
13
¹⁄₄
2400
26
-
.680” Rnd
CPCP 4125 2H CPCP 4125 PALE 13
2
13
¹⁄₄
2400
26
-
.580” Hex
CPCP 4125 3R CPCP 4125 PAMA 15
3
14
¹⁄₄
1920
27
-
.680” Rnd
CPCP 4125 3H CPCP 4125 PAME 15
3
14
¹⁄₄
1920
27
-
.580” Hex
CPCP 4125 4R CPCP 4125 PANA 16
4
15
¹⁄₄
1500
28
-
.680” Rnd
CPCP 4125 4H CPCP 4125 PANE 16
4
15
¹⁄₄
1500
28
-
.580” Hex
CPCP 4130 3R CPCP 4130 3RO 18
¹⁄₂
3
16
¹⁄₂
1920
26
yes
.680” Rnd
CPCP 4130 3H CPCP 4130 3HO 18
¹⁄₂
3
16
¹⁄₂
1920
26
yes
.580” Hex
CPCP 4130 4R CPCP 4130 4RO 19
¹⁄₂
4
17
³⁄₄
1500
27
yes
.680” Rnd
CPCP 4130 4H CPCP 4130 4HO 19
¹⁄₂
4
17
³⁄₄
1500
27
yes
.580” Hex
CPCP 4132 3R
18
3
17
1800
33.23
yes
.680” Rnd
CPCP 4132 3H
18
3
17
1800
33.23
yes
.580” Hex
CPCP 4132 4R
19
4
17
1800
33.23
yes
.680” Rnd
CPCP 4132 4H
19
4
17
1800
33.23
yes
.580” Hex
