CHICAGO PNEUMATIC TOOL CO.
Backfill Tampers
•
Quickly and effectively compact soil around foundations and other structures and are indispensable for compacting backfill in
trenches
•
The CPCP 0003 is well equipped to handle light to medium applications while the CPCP 0004 is ideal for heavier jobs
CPCP 0003, CPCP 0004 & CPCP0035
•
Maximum power - slow, powerful blows efficiently and quickly compact all types of backfill, including clay and soils containing
high percentages of finely crushed or powdered material
•
Adjustable packing maintains a positive air seal
•
Exhaust deflector directs air, moisture and oil away from operator
•
Integral oiler continuously lubricates tool during operation
•
Well-balanced, smooth-operating tool is easily guided by one person
•
1/2” (NPT) air inlet thread
•
For quieter operation, optional mufflers are available
•
CPCP 0035 has built-in muffler
CHICAGO PNEUMATIC TOOL CO.
Sinker Drills
•
Forged steel housings
withstands rugged use
•
Cushioned piston reduces shock
•
Multiposition throttle for easy starting of holes
•
Blower lever for deep hole
cleaning (except CP 0022)
•
Integral oiler provides continuous lubrication
•
Air inlet swivel improves maneuverability
Item #
Valve Type Bore & Stroke (in.) Blows Per Minute (bpm) Net Weight (lbs.) Overall Length (in.)
CPCP 0003 - Air consumption at 90 psi: 18 cfm
CPCP 0003 Simplate
11
⁷⁄₁₆
x 6
800
30
52
CPCP 0035 Simplate
1
¹⁄₂
x 5
¹⁄₂
800
36
4/
¹⁄₄
CPCP 0004 - Air consumption at 90 psi: 28 cfm
CPCP 0004
Ring
2
¹⁄₄
x 6
780
42
50
Item #
Weight
(lbs.)
Length Incl. Drill-Steel
Retainer (in.)
Impact Frequency
(blows/min.)
Max Drilling
Dia (in.)
Max Drilling
Depth (in.)
Standard Hex
Chuck Size (in.)
CPCP 0022 - 30 Pound Class - Air consumption at 90 psi: 56 cfm
CPCP 0022
32
19
⁷⁄₈
2,220
1.7
94.5
⁷⁄₈
x 3
¹⁄₄
CPCP 0022
32
19
⁷⁄₈
2,220
2
94.5
⁷⁄₈
x 4
¹⁄₄
CPCP 0032 - 45-50 Pound Class - Air consumption at 90 psi: 103 cfm
CPCP 0032A.87 54
22
2,200
2
118
⁷⁄₈
x 3
¹⁄₄
CPCP 0032A.87 A 54
23
2,200
2
118
⁷⁄₈
x 4
¹⁄₄
CPCP 0032A-1
54
23
2,200
2
118
1 x 4
¹⁄₄
CPCP 0069 - 60 Pound Class - Air consumption at 90 psi: 130 cfm
CPCP 0069
64
24
¹⁄₄
1,920
2.4
236
⁷⁄₈
x 4
¹⁄₄
CPCP 0069
64
24
¹⁄₄
1,920
2.4
236
1 x 4
¹⁄₄
CPCP 0069-wet
24
¹⁄₄
1,920
2.4
236
⁷⁄₈
x 4
¹⁄₄
