GREENLEE TEXTRON INC.
Breaker - 45 lb. and 55 lb.
Hydraulic
Fairmont
•
Great for breaking sidewalks and curbs or
driving ground rod, and for other small
demolition jobs
•
Clean modular design with few protrusions to
irritate operators’ legs
•
High blow energy provides maximum breaking power
•
Integral rubber damper reduces chisel noise
•
Low noise and vibration levels
•
AVS tools have patented spring-dampened handles that reduce
vibration transmitted to the operator by 80%-90%
•
Two-step trigger
•
Supplied with 12" (305 mm) steel braided whip hoses
GREENLEE TEXTRON INC.
Hydraulic
Flow Control Valve
Fairmont
•
Operates off other equipment’s
hydraulic accessory circuit–no
need for a separate power unit
•
Accepts up to 30 gpm for running
off most skid-steer, tractors and
loaders
•
Variable flow adjustment allows
precise flow control for tool
operation
•
Integral pressure relief valve helps protect hydraulic equipment
and tools
•
All-aluminum body design is lightweight and provides better heat
dissipation
•
Low profile, compact unit is unobtrusive and easy to install.
•
All tool ports have O-Ring boss and accept industry standard
hoses and couplers
Specifications:
•
Hydraulic Ports: Power Source Side – Pressure: 1-1/16" NPT –
SAE O-Ring Boss
•
Power Source Side – Return: 1-1/16" NPT – SAE O-Ring Boss
•
Tool Side – Pressure: 3/4" - 16 SAE O-Ring Boss HTMA Flush
Face Coupling
•
Tool Side – Return: 3/4" - 16 SAE O-Ring Boss HTMA Flush Face
Coupling
•
Maximum Output Flow: 10 gpm
•
Maximum Output Pressure: 2,150 psi
•
Temperature Range: -30° to 140° F
•
Maximum Input Flow: 30 gpm
•
Maximum Input Pressure: 3,000 psi
Item #
Desc.
GRHPB45-1AVS Breaker-- 1
¹⁄₈
x 6” tool shank size,
cushioned/spring-dampened handles
GRHPB45-2AVS Breaker-- 1 X 4
¹⁄₄
” tool shank size,
cushioned/spring-dampened handles
GRHPB55-1AVS Breaker-- 1
¹⁄₈
x 6” tool shank size,
cushioned/spring-dampened handles
Item #
GRHFC30
