565
ITW REDHEAD
Drop-In Anchors
Shell-Type
Multi-Set II®
•
Specified for anchorage into concrete
•
Drop-in, shell-type anchors feature an internally threaded, all-steel shell with expansion cone insert and flush embedment lip
•
Easy removability-use any head style or material bolt rod
•
Below surface setting for easy patch work
ITW REDHEAD
Drop-In Anchors
Shallow Embedment
RX Series
•
ASK ABOUT USING A STOP DRILL
BIT
•
Optimized for use in hollow-core, pre-cast plank and post-tension
slabs
•
Lip keeps anchor flush during installation
•
Shallow drilling—fast installation
•
Inquire about stop-bit to save time and keep drilling from going too
deep
ITW REDHEAD
Drop-In Anchors Setting Tools
Item #
Bolt Size-
Threads per (in.)
Drill Bit Size
in. (mm)
Thread Depth
in. (mm)
Embedment Min.
Hole Depth in. (mm)
Setting Tool Part
Number
Qty/Wt. Tool per
Box (lbs.)
RARL-14
¹⁄₄
- 20
³⁄₈
(9.5)
1 (25.4)
RT-114
100/2.6
RARL-38
³⁄₈
- 16
¹⁄₂
(12.7)
1
⁵⁄₈
(41.3)
RT-138
50/3.4
RARL-12
¹⁄₂
- 13
⁵⁄₈
(15.9)
³⁄₄
(19.1)
2 (50.8)
RT-112
50/5.8
RARL-58
⁵⁄₈
- 11
⁷⁄₈
(22.2)
1 (25.4)
2
¹⁄₂
(63.5)
RT-158
25/7.8
RARL-34
³⁄₄
- 10
1 (25.4)
1
¹⁄₄
(31.8)
3
³⁄₁₆
(81.0)
RT-134
25/11.9
18-8 S.S.
RASRM-14
¹⁄₄
- 20
³⁄₈
(9.5)
1 (25.4)
RT-114
100/2.6
RASRM-38
³⁄₈
- 16
¹⁄₂
(12.7)
1
⁵⁄₈
(41.3)
RT-138
50/3.4
RASRM-12
¹⁄₂
- 13
⁵⁄₈
(15.9)
³⁄₄
(19.1)
2 (50.8)
RT-112
50/5.8
RASRM-58
⁵⁄₈
- 11
⁷⁄₈
(22.2)
1 (25.4)
2
¹⁄₂
(63.5)
RT-158
25/7.8
RASRM-34
³⁄₄
- 10
1 (25.4)
1
¹⁄₄
(31.8)
3
³⁄₁₆
(81.0)
RT-134
25/11.9
Item #
Bolt
Size-
Threads
per (in.)
Drill Bit
Size in.
Thread
Depth
in.
Embedment
Min. Hole
Depth in.
(mm)
Qty/Wt.
per Box
(lbs.)
RARX-38
³⁄₈
- 16
¹⁄₂
³⁄₈
³⁄₄
100/3.5
RARX-12
¹⁄₂
- 13
⁵⁄₈
¹⁄₂
1
50/3.0
Item #
Desc.
RART-114
¹⁄₄
” Tool
RART-138
³⁄₈
” Tool
RART-112
¹⁄₂
” Tool
RART-158
⁵⁄₈
” Tool
RART-134
³⁄₄
” Tool
RARTX-138
³⁄₈
” Tool RX
Series
RARTX-112
¹⁄₂
” Tool RX
Series
