www.edgecs.com
566
Anchors & Fastener Systems
Spokane, WA 509-535-9841
Billings, MT 406-248-7196
Yakima, WA 509-248-1144
Gillette, WY 307-682-8522
ITW REDHEAD
Sleeve Anchors
Carbon Steel
Dynabolt®
Carbon steel with zinc plating
Typical applications - Shelf ledgers, electrical boxes, conduit
Environment - Interior (non-corrosive)
Level of corrosion - Low
ITW REDHEAD
Sleeve Anchors
Stainless Steel
Dynabolt®
Type 304 stainless steel
Typical applications - Cladding and brick ties
Environment - Slight to moderate degree of pollution
Level of corrosion - Medium
ITW REDHEAD
Blow-Out Bulb
•
Qty/Bag: 1
Item #
Head Style
Anchor Dia. (in.)
& Drill Bit Size
(Threads) per Inch
Effective Anchor
Length in. (mm)
Bolt Dia.
(in.) / Threads
per Inch
Min.
Embedment
in. (mm)
Max. Thickness of
Material to be
Fastened in. (mm)
Qty/Wt per
Box (lbs.)
RAHN-1405 Hex Nut
¹⁄₄
- 20
⁵⁄₈
(15.9)
³⁄₁₆
/24
¹⁄₂
(12.7)
¹⁄₈
(3.2)
100/ 1.6
RAHN-5860 Hex Nut
⁵⁄₈
- 11
6 (152.4)
¹⁄₂
/13
2 (50.8)
4 (101.6)
10/ 4.9
RAHX-1222 Hex Coupling
(Rod Hanger)
¹⁄₂
- 13
2
¹⁄₄
(57.2)
¹⁄₂
/13 Hanger
1
⁷⁄₈
(47.6)
25/ 6.5
RAHX-3822 Hex Coupling
(Rod Hanger)
³⁄₈
- 16
1
⁷⁄₈
(47.6)
³⁄₈
/16 Hanger
1
¹⁄₂
(38.1)
50/ 6.0
Item #
Anchor Dia.
(in.) & Drill Bit
Size (Threads)
per Inch
Effective
Anchor
Length in.
(mm)
Bolt Dia. (in.)
/Threads per
Inch
Min.
Embedment
in. (mm)
Max. Thickness of
Material to be
Fastened in. (mm)
Qty/Wt per
Box (lbs.)
Qty/Wt per
Master
Carton (lbs.) Head Style
RASFS-1430
¹⁄₄
- 20
3
¹⁄₈
(79.4)
³⁄₁₆
/24
1
¹⁄₈
(28.6)
3 (76.2)
100/ 3.8 1000/ 38 Flat Head
RASFS-3826
³⁄₈
- 16
2
⁷⁄₈
(73.0)
⁵⁄₁₆
/18
1
¹⁄₂
(38.1)
1
³⁄₈
(34.9)
50/ 3.8
500/ 40 Flat Head
RASFS-3840
³⁄₈
- 16
4 (101.6)
⁵⁄₁₆
/18
1
¹⁄₂
(38.1)
2
¹⁄₂
(63.5)
50/ 5.3
400/ 44 Flat Head
RASHN-1230
¹⁄₂
- 13
3 (76.2)
³⁄₈
/16
1
⁷⁄₈
(47.6)
1
¹⁄₈
(28.6)
25/ 4.0
200/ 33
Hex Nut
RASRS-1420
¹⁄₄
- 20
2 (50.8)
³⁄₁₆
/24
1
¹⁄₈
(28.6)
⁷⁄₈
(22.2)
100/ 2.7 1000/ 28
Round
Head
Item #
RABB-10
Need anchors?
We’ve got them.
Give us a call.
