TYPE HB-Hollo-Bolt® - Hex Head

Hollow Section (HSS) Connection

"• Suitable for hollow sections, tubes and where access is available from one side only

• For corrosion protection, the Hollo-Bolt® comes with additional JS500 protection as standard or hot dip galvanized

• Sizes 5/8"" and 3/4"" have a patented collapse mechanism for optimized clamping force

• Finish/Material options: Steel, bright zinc plated (with JS500 protection), hot dip galvanized or stainless steel grade 316

• Contact Edge for detailed specs and design data"
Scroll down for full product description

Product Documents

ICC Data Sheet

Item # Size Metric (US Equiv.) ZMaterialUnit Of
Measure
 PriceMaterial
List for Quote		Buy
Online
Expand Table to Show All Columns
LDLHBM08 #1M8 ([5/16]”)Bright Zinc Ea. $ 4.94 Add Buy
LDLHBM08 #1 HDGM8 ([5/16]”)Hot Dip Galvanized Ea. $ 6.15 Add Buy
LDLHBM08 #2M8 ([5/16]”)Bright Zinc Ea. $ 9.78 Add Buy
LDLHBM08 #2 HDGM8 ([5/16]”)Hot Dip Galvanized Ea. $ 12.23 Add Buy
LDLHBM08 #3M8 ([5/16]”)Bright Zinc Ea. $ 14.64 Add Buy
LDLHBM10 #1M10 ([3/8]”)Bright Zinc Ea. $ 5.98 Add Buy
LDLHBM10 #1 HDGM10 ([3/8]”)Hot Dip Galvanized Ea. $ 7.50 Add Buy
LDLHBM10 #1 SSM10 ([3/8]”)Stainless Steel Ea. $ 25.44 Add Buy
LDLHBM10 #2M10 ([3/8]”)Bright Zinc Ea. $ 11.94 Add Buy
LDLHBM10 #2 HDGM10 ([3/8]”)Hot Dip Galvanized Ea. $ 14.93 Add Buy
LDLHBM10 #3M10 ([3/8]”)Bright Zinc Ea. $ 17.93 Add Buy
LDLHBM10 #3 HDGM10 ([3/8]”)Hot Dip Galvanized Ea. $ 22.36 Add Buy
LDLHBM12 #1M12 ([1/2]”)Bright Zinc Ea. $ 7.99 Add Buy
LDLHBM12 #1 HDGM12 ([1/2]”)Hot Dip Galvanized Ea. $ 9.91 Add Buy
LDLHBM12 #1 SSM12 ([1/2]”)Stainless Steel Ea. $ 40.79 Add Buy
LDLHBM12 #2M12 ([1/2]”)Bright Zinc Ea. $ 15.85 Add Buy
LDLHBM12 #2 HDGM12 ([1/2]”)Hot Dip Galvanized Ea. $ 19.77 Add Buy
LDLHBM12 #3M12 ([1/2]”)Bright Zinc Ea. $ 27.04 Add Buy
LDLHBM12 #3 HDGM12 ([1/2]”)Hot Dip Galvanized Ea. $ 33.78 Add Buy
LDLHBM16 #1M16 ([5/8]”)Bright Zinc Ea. $ 12.73 Add Buy
LDLHBM16 #1 HDGM16 ([5/8]”)Hot Dip Galvanized Ea. $ 15.91 Add Buy
LDLHBM16 #2M16 ([5/8]”)Bright Zinc Ea. $ 25.40 Add Buy
LDLHBM16 #2 HDGM16 ([5/8]”)Hot Dip Galvanized Ea. $ 31.70 Add Buy
LDLHBM16 #3M16 ([5/8]”)Bright Zinc Ea. $ 38.09 Add Buy
LDLHBM16 #3 HDGM16 ([5/8]”)Hot Dip Galvanized Ea. $ 47.61 Add Buy
LDLHBM20 #1M20 ([3/4]”)Bright Zinc Ea. $ 23.76 Add Buy
LDLHBM20 #1 HDGM20 ([3/4]”)Hot Dip Galvanized Ea. $ 29.70 Add Buy
LDLHBM20 #2M20 ([3/4]”)Bright Zinc Ea. $ 50.08 Add Buy
LDLHBM20 #2 HDGM20 ([3/4]”)Hot Dip Galvanized Ea. $ 62.56 Add Buy
LDLHBM20 #3M20 ([3/4]”)Bright Zinc Ea. $ 75.06 Add Buy
Item Specifications
x

Item # Size Metric (US Equiv.) ZBolt LengthMaterialClamping Thickness WOuter Ply¹ min tSleeve Length (in.)Outer Ø LTorque (ft.lb.)Safe Working Loads (5:1 Factor Of Safety) Tensile Safe Working Loads (5:1 Factor Of Safety) Single SUnit Of
Measure
 PriceMaterial
List for Quote		Buy
Online
LDLHBM08 #1M8 ([5/16]”)2”Bright Zinc[1/8]”-[7/1[3/16]”[9/16]”178991,124 Ea. $ 4.94 Add Buy
LDLHBM08 #1 HDGM8 ([5/16]”)2”Hot Dip Galvanized[1/8]”-[7/1[3/16]”[9/16]”178991,124 Ea. $ 6.15 Add Buy
LDLHBM08 #2M8 ([5/16]”)2[3/4]”Bright Zinc[7/8]”-1[51[5/16]”[9/16]”178991,124 Ea. $ 9.78 Add Buy
LDLHBM08 #2 HDGM8 ([5/16]”)2[3/4]”Hot Dip Galvanized[7/8]”-1[51[5/16]”[9/16]”178991,124 Ea. $ 12.23 Add Buy
LDLHBM08 #3M8 ([5/16]”)3[5/8]”Bright Zinc1[5/8]”-2[2[11/16]”[9/16]”178991,124 Ea. $ 14.64 Add Buy
LDLHBM10 #1M10 ([3/8]”)2[1/4]”Bright Zinc[1/8]”-[7/1[3/16]”[3/4]”331,9102,248 Ea. $ 5.98 Add Buy
LDLHBM10 #1 HDGM10 ([3/8]”)2[1/4]”Hot Dip Galvanized[1/8]”-[7/1[3/16]”[3/4]”331,9102,248 Ea. $ 7.50 Add Buy
LDLHBM10 #1 SSM10 ([3/8]”)2[1/4]”Stainless Steel[1/8]”-[7/1[3/16]”[3/4]”331,9102,248 Ea. $ 25.44 Add Buy
LDLHBM10 #2M10 ([3/8]”)3”Bright Zinc[7/8]”-1[51[7/8]”[3/4]”331,9102,248 Ea. $ 11.94 Add Buy
LDLHBM10 #2 HDGM10 ([3/8]”)3”Hot Dip Galvanized[7/8]”-1[51[7/8]”[3/4]”331,9102,248 Ea. $ 14.93 Add Buy
LDLHBM10 #3M10 ([3/8]”)3[5/8]”Bright Zinc1[5/8]”-2[2[5/8]”[3/4]”331,9102,248 Ea. $ 17.93 Add Buy
LDLHBM10 #3 HDGM10 ([3/8]”)3[5/8]”Hot Dip Galvanized1[5/8]”-2[2[5/8]”[3/4]”331,9102,248 Ea. $ 22.36 Add Buy
LDLHBM12 #1M12 ([1/2]”)2[3/8]”Bright Zinc[1/8]”-1”1[3/8]”[13/16]”592,3603,372 Ea. $ 7.99 Add Buy
LDLHBM12 #1 HDGM12 ([1/2]”)2[3/8]”Hot Dip Galvanized[1/8]”-1”1[3/8]”[13/16]”592,3603,372 Ea. $ 9.91 Add Buy
LDLHBM12 #1 SSM12 ([1/2]”)2[3/8]”Stainless Steel[1/8]”-1”1[3/8]”[13/16]”592,3603,372 Ea. $ 40.79 Add Buy
LDLHBM12 #2M12 ([1/2]”)3[5/8]”Bright Zinc1”-1[13/162[1/4]”[13/16]”592,3603,372 Ea. $ 15.85 Add Buy
LDLHBM12 #2 HDGM12 ([1/2]”)3[5/8]”Hot Dip Galvanized1”-1[13/162[1/4]”[13/16]”592,3603,372 Ea. $ 19.77 Add Buy
LDLHBM12 #3M12 ([1/2]”)4[1/4]”Bright Zinc1[13/16]”-3[1/8]”[13/16]”592,3603,372 Ea. $ 27.04 Add Buy
LDLHBM12 #3 HDGM12 ([1/2]”)4[1/4]”Hot Dip Galvanized1[13/16]”-3[1/8]”[13/16]”592,3603,372 Ea. $ 33.78 Add Buy
LDLHBM16 #1M16 ([5/8]”)3”Bright Zinc[1/2]”-1[1[5/16]”1[5/8]”1[1/16]”1404,7206,744 Ea. $ 12.73 Add Buy
LDLHBM16 #1 HDGM16 ([5/8]”)3”Hot Dip Galvanized[1/2]”-1[1[5/16]”1[5/8]”1[1/16]”1404,7206,744 Ea. $ 15.91 Add Buy
LDLHBM16 #2M16 ([5/8]”)4”Bright Zinc1[1/8]”-2”[5/16]”2[1/2]”1[1/16]”1404,7206,744 Ea. $ 25.40 Add Buy
LDLHBM16 #2 HDGM16 ([5/8]”)4”Hot Dip Galvanized1[1/8]”-2”[5/16]”2[1/2]”1[1/16]”1404,7206,744 Ea. $ 31.70 Add Buy
LDLHBM16 #3M16 ([5/8]”)4[3/4]”Bright Zinc2”-2[13/16[5/16]”3[5/16]”1[1/16]”1404,7206,744 Ea. $ 38.09 Add Buy
LDLHBM16 #3 HDGM16 ([5/8]”)4[3/4]”Hot Dip Galvanized2”-2[13/16[5/16]”3[5/16]”1[1/16]”1404,7206,744 Ea. $ 47.61 Add Buy
LDLHBM20 #1M20 ([3/4]”)3[5/8]”Bright Zinc[1/2]”-1[5[5/16]”1[15/16]”1[5/16]”2217,8688,992 Ea. $ 23.76 Add Buy
LDLHBM20 #1 HDGM20 ([3/4]”)3[5/8]”Hot Dip Galvanized[1/2]”-1[5[5/16]”1[15/16]”1[5/16]”2217,8688,992 Ea. $ 29.70 Add Buy
LDLHBM20 #2M20 ([3/4]”)4[3/4]”Bright Zinc1[5/16]-2[[5/16]”3”1[5/16]”2217,8688,992 Ea. $ 50.08 Add Buy
LDLHBM20 #2 HDGM20 ([3/4]”)4[3/4]”Hot Dip Galvanized1[5/16]-2[[5/16]”3”1[5/16]”2217,8688,992 Ea. $ 62.56 Add Buy
LDLHBM20 #3M20 ([3/4]”)5[7/8]”Bright Zinc2[3/8]”-3[[5/16]”4”1[5/16]”2217,8688,992 Ea. $ 75.06 Add Buy
